Rocking Tube Furnace with Quartz Tube & Vacuum Flange (Optional 1-2" ) - GSL1100XSK

Furnace Structure

• Energy-saving high purity Al2O3 fibrous insulation liner
• Stainless steel shells with adjustable height

Power

• AC 110V single-phase or AC 220V single phase
• (Please select the tube size and the rated voltage in the options bar)
• 1.2KW

Working Temperature

• Max. Temperature: 1100 °C (< 1 hr)
• Continuous working temperature: 1000 °C
• Max. Heating Rate: 10°C /min

• Heating Zone Length: 12" (300mm)
• Constant Temperature Zone: 3.1" (80mm)

Temperature Controller

• PID automatic control and auto-tune function.
• 30 programmable segments for precise thermal processing.
• Built-in protection for the over-heated and broken thermocouple.
• Temperature Accuracy: +/- 1 °C.
• K type thermocouple.

• 1" O.D x 0.87" I.D x 24" L Quartz tube or 2.0" O.D x 1.75" I.D x 24" L-quartz tube
• (Please select the tube size and the rated voltage in the options bar)
• Two fibrous ceramic tube blocks are included for blocking heat radiation generated from the tube center.
•

• 2" default flange with 1/4'' Barbed fittings, 1/4'' tube feedthrough port (for 1/4" O.D thermocouple insert) and a KF25 vacuum portclick bottom right picture to see details )
• 1" flange has no thermocouple insert ( click the bottom left picture to see details )

  1" Flange Set  2" Flange Set

• Both flanges will come standard with 3/8" barbed hose fittings
• In order to increase the throughput and achieve a high vacuum, you may replace the standard barbed hose fitting with the KF25 adapter (please click the underline to order).
• For supplying high-pressure gas, you may replace the standard barbed hose fitting with the 304SS 1/4" Swagelok® Tube Fitting x 1/4" BSPP Male Connector (please click the underline to order).

Vacuum Pressure (optional)

• 50 m-torr can be achieved by a mechanical pump
• 10^-5 torr can be reached by turbopump
• Please click the picture below to order a vacuum pump.



Pressure Measurement

• Mechanical Vacuum Gauge (included as standard accessory), which measures within a pressure range of -0.1 to 0.15Mpa.

Rocking Station

• DC motor, 40W
• LCD digital display with adjustable speed from 10 - 70 RPM
• Rocking angle: 9º max.
• Timer: 1-1199min or continuous running
