Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS

Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS

Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS

VBF-1200S-MS is a molten salt reactor for studies of molten salt electrolysis.

Features

Benchtop furnace design to accommodate a Ø4" OD reactor
Quartz vessel for operations up to 1100°C
Three-electrode system
Gas inlet/outlet
In-situ type K thermocouple

SPECIFICATION:

Power	Choice of working voltage AC 110-120V, Single Phase, 50/60Hz, 20A, 1.5KVA AC 208-240V, Single Phase, 50/60Hz, 15A, 1.8KVA
Working Temperature	<1100°C, continously
Max. Heating Rate	20 °C/min Max.
Max Pressure	3 psig
Reaction Vessel	4" quartz tube, 100 OD x 94 ID x 300 L (mm), Capacity: 1.7 L SS 316 hermetic flange with six 1/4" compression tube fittings Three-electrode system Gas inlet and outlet Type K in-situ thermocouple One alumina thermal block.
Heating Area	Ø120 ID × 200 H mm
Optional Crucibles	Choice of different alumina crucibles Ø40 × 40 mm Ø60 × 60 mm
Electrodes Connections	Ø 3 mm copper sheathed with Ø6 alumina tube, up to 55A Copper barrel connectors for connections with any types of Ø6 mm electrodes (electrodes are not included)
Temperature controller	One digital temperature controller is built in with an accuracy of ±1°C PID automatic control and auto-tune function. 30 programmable segments for precise process Built-in protection for overheating and broken thermocouples. K-type thermocouple
DC Power Supply (Optional)	A programmable DC power supply is optional up to 30V DC, and 70A Max
Compliance	CE Certified NRTL Certification is available upon request, additional charges will apply

Select Voltage

From $3,499.30

Original: $9,998.00

-65%

Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS—

$9,998.00

$3,499.30

More Images

Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS - Image 2

Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS - Image 3

Three-electrode Molten Salt Reactor with a 4" Quartz Vessel - VBF-1200S-MS

VBF-1200S-MS is a molten salt reactor for studies of molten salt electrolysis.

Features

Benchtop furnace design to accommodate a Ø4" OD reactor
Quartz vessel for operations up to 1100°C
Three-electrode system
Gas inlet/outlet
In-situ type K thermocouple

SPECIFICATION:

Power	Choice of working voltage AC 110-120V, Single Phase, 50/60Hz, 20A, 1.5KVA AC 208-240V, Single Phase, 50/60Hz, 15A, 1.8KVA
Working Temperature	<1100°C, continously
Max. Heating Rate	20 °C/min Max.
Max Pressure	3 psig
Reaction Vessel	4" quartz tube, 100 OD x 94 ID x 300 L (mm), Capacity: 1.7 L SS 316 hermetic flange with six 1/4" compression tube fittings Three-electrode system Gas inlet and outlet Type K in-situ thermocouple One alumina thermal block.
Heating Area	Ø120 ID × 200 H mm
Optional Crucibles	Choice of different alumina crucibles Ø40 × 40 mm Ø60 × 60 mm
Electrodes Connections	Ø 3 mm copper sheathed with Ø6 alumina tube, up to 55A Copper barrel connectors for connections with any types of Ø6 mm electrodes (electrodes are not included)
Temperature controller	One digital temperature controller is built in with an accuracy of ±1°C PID automatic control and auto-tune function. 30 programmable segments for precise process Built-in protection for overheating and broken thermocouples. K-type thermocouple
DC Power Supply (Optional)	A programmable DC power supply is optional up to 30V DC, and 70A Max
Compliance	CE Certified NRTL Certification is available upon request, additional charges will apply
