1700C Bottom Loading Vertical Furnace (280Dx300H mm, 13L) with Dual Stages - VBF1600X-Z
HomeStore

1700C Bottom Loading Vertical Furnace (280Dx300H mm, 13L) with Dual Stages - VBF1600X-Z

1700C Bottom Loading Vertical Furnace (280Dx300H mm, 13L) with Dual Stages - VBF1600X-Z

VTF-1600X-Z is a vertical furnace with dual heating stages for fast sample loading and retrieving. It is a time-saving product for continuous thermal treatment for different batches of samples. It also features a rapid thermal process and a fast cooling procedure. Both of the stages are slid on the rails for easy and safe operation. The system can be fully automated at an extra cost.

SPECIFICATIONS


Furnace Features
  • Dual sample stages for quick loading and retrieving on the bottom of the furnace
  • Rapid thermal heating and cooling process.
  • Stages are slid on the rails for easy operation. and Time-saving
  • High-purity thermal insulation material for better energy saving
  • Air-cold steel case for safe operation
Working Temperature
  • 1600 °C, continuously
  • 1700 °C, < 1 hr

Heating Chamber
  • Cylindrical, 280 (ID) x 300 (H) mm
  • Capacity: ~ 18 L

Power
  • 220 VAC, 50/60 Hz
  • Max. Power: ~ 13 kW

Heating Element
  • MoSi2 ( 1750 grade )

Max. Heating Rate
  • ≤ 10 °C/min (Recommended)

Max Cooling Rate
  • ≤ 20 °C/min (Recommended)

Thermocouple
  • Type B

Temperature Control
  • Touchscreen display unit for easy control.
  • Max. 30 programmable segments.
  • ± 1 ºC precise temperature control during the dwelling
  • Overheat alarm, Deviation alarm, broken thermocouple alarm
  • RS 485 communication port for remote control.
  • PC software and interface are included
  • Overheat alarm, electric leakage protection
Temperature controller (optional)
  • MTS02-Y Temperature control software kit (for YD518P series controllers) + 15" laptop package is available at the options bar. Click for detailed information about the MTS02-Y software kit.
  • You may upgrade the temperature controller to the Eurotherm 3000 series Temperature Controller which provides ± 0.1 ºC precise temperature control during dwelling and is fully compatible with LabVIEW. This package includes a Eurotherm 3000 series temperature controller, a communication cable (RS485 - USB), and a software CD.
Laptop, software & WiFi Control (Optional)

  • Brand new laptop with Microsoft Windows 10 and Microsoft Office 2013 (30-day free trial) for immediate use.
  • Labview-based Temperature Control System enables a user to edit temperature profiles, manage heat-treatment recipes, and record and plot data for MTI furnaces.
  • file, manage heat-treatment recipes, and record and plot data for MTI furnaces.
  • A wireless remote control provides up to 300 meters of operating range.
  • The above features are available upon request at an extra cost (up to $1,000). Please contact us for more information.

Compliance
  • CE Certified
  • NRTL (UL61010) or CSA certification is available upon request at extra cost.


Application Notes
  • To obtain accurate temperature inside the tube furnace, you shall calibrate the temperature before use, please click here to learn how.



$16,099.30

Original: $45,998.00

-65%
1700C Bottom Loading Vertical Furnace (280Dx300H mm, 13L) with Dual Stages - VBF1600X-Z—

$45,998.00

$16,099.30

More Images

1700C Bottom Loading Vertical Furnace (280Dx300H mm, 13L) with Dual Stages - VBF1600X-Z - Image 2
1700C Bottom Loading Vertical Furnace (280Dx300H mm, 13L) with Dual Stages - VBF1600X-Z - Image 3
