PFSA Proton-Exchange Membrane (10cm*10cm) for Electrolyzers or Fuel Cells, EFC-PFSA-PEM
The PSFA proton-exchange membrane (PFSA PEM) is used to separate the anode and cathode compartment of PEM water electrolyzers or fuel cells because of its relatively thick nature (~125 microns) and robustness compared to other thinner PFSA membranes.
Specifications:
| Part Number | EFC-PFSA-PEM (N115 and N117) |
| Sheet Size | 10cm *10cm (other sizes are available upon request) |
| Thickness | 125 um |
| Conductivity | > 0.1 S/cm |
| Swelling | 18%-24% |
| Total Acid Amount | 1.0 meq/g |
| Water Content | 5% |
Select Types
From $48.65
Original: $139.00
-65%PFSA Proton-Exchange Membrane (10cm*10cm) for Electrolyzers or Fuel Cells, EFC-PFSA-PEM—
$139.00
$48.65PFSA Proton-Exchange Membrane (10cm*10cm) for Electrolyzers or Fuel Cells, EFC-PFSA-PEM
The PSFA proton-exchange membrane (PFSA PEM) is used to separate the anode and cathode compartment of PEM water electrolyzers or fuel cells because of its relatively thick nature (~125 microns) and robustness compared to other thinner PFSA membranes.
Specifications:
| Part Number | EFC-PFSA-PEM (N115 and N117) |
| Sheet Size | 10cm *10cm (other sizes are available upon request) |
| Thickness | 125 um |
| Conductivity | > 0.1 S/cm |
| Swelling | 18%-24% |
| Total Acid Amount | 1.0 meq/g |
| Water Content | 5% |
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The PSFA proton-exchange membrane (PFSA PEM) is used to separate the anode and cathode compartment of PEM water electrolyzers or fuel cells because of its relatively thick nature (~125 microns) and robustness compared to other thinner PFSA membranes.
Specifications:
| Part Number | EFC-PFSA-PEM (N115 and N117) |
| Sheet Size | 10cm *10cm (other sizes are available upon request) |
| Thickness | 125 um |
| Conductivity | > 0.1 S/cm |
| Swelling | 18%-24% |
| Total Acid Amount | 1.0 meq/g |
| Water Content | 5% |
