Vacuum Planetary Centrifugal Mixer w/ Two Containers (600ml) & Optional Ball Mill Jars - MSK-PCV-300-LD

The planetary centrifugal vacuum mixer MSK-PCV-300-LD is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste. The vacuum mixing capability is integrated for the best mixing results. The standard package includes two 300 ml of containers and counter-weights. High-throughput adapters are also available for 6 samples (7 ml per sample) mixing per batch. Also, you can use the device as an ultra-high-energy ball milling up to 600 G impact force with special alloy jars.

SPECIFICATIONS

Features	Compared with other brands of the planetary centrifugal mixer, MSK-PCV-300 has the following unique features: Mixing under vacuum for deaeration Dual containers for larger quantity Minimized contamination (no metal mixing blade) Centrifugal acceleration: 450g Max. Sample Materials Nanopowders, ceramic powders Slurry Paste Mechanical alloying with special alloy jars (optional)
Voltage Input	Single Phase AC 208 - 240V, 50/60 Hz
Power	Maximum: 1350 W Motor Power: 750 W
Mixing	Planetary Centrifugal Vacuum Mixing The centrifugal force of rotation and revolution induces convection, homogenizing the materials With the vacuum pressure, submicron air bubbles can be efficiently eliminated from the materials Max viscosity: 30000 Pa S
Vacuum Capability	Pumping Rate: 165 L/min Ultimate Vacuum: -98 kPa Built-in vacuum pump with integrated control
Speed	Fixed speed ratio (0.6X between main plate revolution and container rotating) Sample Platen Rotation (revolution motion): 200 rpm - 2,000 rpm (adjustable) Container Spin (rotation motion): 120 rpm - 1,200 rpm (fixed at 0.6X of the revolution speed)
Containers and Counter-Weights	Two standard containers and counter-weights are included Two 300 ml containers with gas vent, made of high-density Polyethylene (Pic. 1, 2) Counter-weights (10, 20, 50 g) with adapter, made of high-density Polyethylene (Pic. 3) Pic. 1 Pic.2  Pic. 3
Optional containers	Two 100 ml containers (not included) with adapter and gas vent, made of high-density Polyethylene (Pic. 1) Two 30 ml containers (not included) with adapter and gas vent, made of high-density Polyethylene (Pic. 2) 26 mm Dia. adapter for 30 mL syringe (not included), made of high-density Polyethylene (Pic. 3) Two 3-container-sets (10ml) in one adapter are available for high throughput research (6 samples per batch) You may also order the special alloy jars for smaller sized ball milling applications (the rightmost pic, click here to see a video)                             Pic. 1                        Pic. 2                   Pic. 3                    Pic. 4                 Pic. 5                    Pic. 6
Control Panel Fig.1  Fig.2	Touch screen control panel to program speed and time Store up to 6 programs in memory, as shown in Fig.1 3 programmable segments, as shown in Fig.2. For example: 800 rpm revolution speed (480 rpm rotation speed) for 60 sec; 1500 rpm revolution speed (900 rpm rotation speed) for 150 sec; 1000 rpm revolution speed (600 rpm rotation speed) for 60 sec. The maximum running time for each segment is 200 sec. The maximum total running time is 600 sec The rotation direction could be either clockwise (mode A) or counter-clockwise (mode B)
Safety and Protection	Safety warnings and interlocks are integrated. The unit automatically stops when The unit is overloaded with the sample The sample is loaded in an unbalanced way The top cover is opened
Application Notes	Always use the mixer on a level & stable surface for best performance and maximum safety Do not use the mixer in a hazardous atmosphere, or with flammable, explosive, corrosive, poisonous material! Check the chemical resistance of the container with different materials before loading the sample!!! Do not overload the mixer! Stop the mixing operation immediately if abnormal sound/vibration is observed Use a digital balance to make sure the sample loading is balanced before mixing Double-check if the containers are mounted correctly and securely before mixing Do not open the cover lid until the rotation has completely stopped! Do not retrieve the containers and/or put a hand close to the mixing fixture while the rotation has not completely stopped! Only use the included containers for the mixing operation! Please make sure there is no foreign object in the mixer before mixing Please click underline to learn Centrifugal Force calculation Please do not use it under Ar gas. Please consider our MSK-PCV-310AR if Ar gas is required
