Compact Vacuum Planetary Centrifugal Mixer w/ Two 150ml Containers & Temp. Monitor - MSK-PCE-V2150

Features

• Mixing under vacuum for deaeration
• Automatic and Manual modes of operation
• Combination of rotation and revolution to mix samples evenly
• Temperature monitor for the chamber
• Compact size to fit in the glove box
• Minimized contamination (no metal mixing blade)
• Mix, disperse, and degas samples simultaneously
• Process up to two samples simultaneously
• Acceleration gravity: ~ 259 g
• Brushless motor to allow to use in an Ar environment

• Single Phase AC 208 - 240V, 50 Hz
• Maximum: 1000 W
• 110V is available with a 1500W transformer

• Planetary Centrifugal Vacuum Mixing
• The centrifugal force of rotation and revolution induces convection, homogenizing the materials.
• With the vacuum pressure, submicron air bubbles can be efficiently eliminated from the materials.

• - 0.085 MPa Max.
• The vacuum pump is not included in the standard package. Please click the picture below to order a vacuum pump.



• 1-999 seconds

• Fixed speed ratio (container rotation speed = sample platen revolution speed x 0.6 )
• Sample Platen (revolution motion): 10-2000 rpm, accuracy 1 rpm
  • Low Speed: 10-1499 rpm, continuous
  • High Speed: 1500-2000 rpm, 7.5min Max.

• Two 150ml standard containers are included. 30ml containers are available upon request.

  • Type	Container	Max Sample Volume	Max Sample Weight
    Standard	150 ml	75 ml	150 g
    Optional	30 ml	15 ml

• Warning: overload may damage the device. Please follow both the volume and weight limit as above when loading the sample.

• Easy control touch screen panel
• Store up to 8 programs in memory at Automatic Mode, as shown in Fig.1
• 3 programmable segments with adjustable speed, time, and vacuum values, as shown in Fig.2.

Fig.1 Fig.2

• Chamber temperature is monitored by an IR sensor and displayed on the touchscreen. The alarm temperature can be set for various sample properties and experimental purposes.

• Always use the mixer on a level & stable surface for best performance and maximum safety.
• Do not use the mixer in a hazardous atmosphere, or with flammable, explosive, corrosive, poisonous material.
• Check the chemical resistance of the container with different materials before loading the sample.
• Do not overload the mixer! Stop the mixing operation immediately if abnormal sound/vibration is observed.
• Use a digital balance to make sure the sample loading is balanced before mixing.
• Double-check if the containers are mounted correctly and securely before mixing.
• Do not open the cover lid until the rotation has completely stopped. Do not retrieve the containers and/or put a hand close to the mixing fixture while the rotation has not completely stopped.
• Only use the included containers for the mixing operation. Please make sure there is no foreign object in the mixer before mixing
• Please click underline to learn Centrifugal Force calculation.
