Corning EAGLE XG wafer 100mm dia x 0.5mm, 2 sp surface quality 60/40 - CorningEagle100D05C2opt
HomeStore

Corning EAGLE XG wafer 100mm dia x 0.5mm, 2 sp surface quality 60/40 - CorningEagle100D05C2opt

Corning EAGLE XG wafer 100mm dia x 0.5mm, 2 sp surface quality 60/40 - CorningEagle100D05C2opt

    Features:
    • Corning EAGLE XGĀ  Glass SubstratesĀ
      Suggested Max. Use Temperature: 675 deg C (1,247 deg F )Ā
    • Dimension:Ā Ā 100 mm (+/-0.2mm) in diameter Ā x 0.5 mm(+/-0.05mm)
    • High transmission (75-80 %)
    • Low defect densities
    • Low ohmic values
    • Both Sides Optically Clear with Surface Quality; 60/40 and Surface Roughness Ra: < 0.5 nm RMS
    • Edge : CNC ground
    • Non- effective area: 3.0mm Border
    • Highly transparentĀ
    • LCD and OLED applications

    For the properties of Corning EAGLE XG Glass,please click here.
    For the Data of BOROFLOATĀ® Borosilicate Float Glass,please click here.
