EQ-SPC-Series are splittable pouch cells made of Nylon or Peek, which are designed for testing pouch cells with max electrode dimension of different size. Its detachable design allows you to test the pouch cell behavior as well as structural changes of electrode easily, quickly and cost effectively.

Specifications
Design Fearture	Easy assembling by only four cap mounting screws Easy to separate after test for microstructure analysis Space saving, compact design allows you put it into the glove box
Material (Please select at options bar)	Nylon or PEEK (Poly Ether Ketone) selectable from product options bar Body: Electrolyte corrosive-proof Nylon which can sustain with temperature up to 80ºC and O-ring: Sealed by electrolyte corrosive-proof PTFE O-rings Body: PEEK (Poly Ether Ketone), which is a semicrystalline thermoplastic with excellent mechanical and chemical resistance properties that are retained to high temperatures and O-ring: Sealed by electrolyte corrosive-proof FKM O-rings
Appearance	EQ-SPC-654519	EQ-SPC-804019	EQ-SPC-955208	EQ-SPC-30529525
Inside chamber Dimensions (Customized size pouch cell are available upon request)	65 mm H x 45mm W x19 mm Thick	80 mm H x 40mm W x 19 mm Thick	95 mm H x 52mm W x 8 mm Thick	305 mm H x 295.5 mm W x 25.4 mm Thick
Suggested Max. electrode area	60mm H x 40 mm	75 mm H x 35 mm	80mm H x 50mm	300mm H x 395mm
Outside Case Dimensions	89 mm H x 75 mm W x 53 mm Thick	93 mm H x 85 mm W x 55 mm Thick	120mm H x 85 mm W x 40mm Thick	317.5 mm H x 323 mm W x 86 mm Thick
Structure	One digital pressure gauge installed on top to monitor pressure. You may remove the gauge and use 1/4 female port to inject electrolyte into the pouch cell Two stainless steel contacts to connect anode and cathode by the screw Max. working temperature: 80°C for Nylon, and 120°C for PEEK Max. working pressure: 36psi (0.25MPa) for Nylon and 60psi (0.4Mpa) for PEEK
Application Note	In order to make metal air pouch cell, you can drill holes in the case. We can help you do that at extra cost You may use MTI die cutter to prepare electrode via layer by layer or make winding type pouch cell electrode (click picture below to see the machine) You may need an ultrasonic welder to welding electrode tape to connect to the split cell
