SS316 Reaction Vessel (1100 ml) with 6 x 1/4" Feedthrough Ports for VBF-600S - RC-SS1100FT6
SS316 Reaction Vessel (1100 ml) with 6 x 1/4" Feedthrough Ports for VBF-600S - RC-SS1100FT6
RCSS31676 is an SS316 stainless steel tube with a vacuum flange and six 1/4" dia. feedthroughs, designed for the reactor of a molten salt battery.
For the furnace used with VBF-600S vessel, please choose VBF1200S
| Structure | SS316 Stainless Steel |
Dimension
|
 Ā 76mm OD x 70mm ID x 300 mm height
|
| Volume | 1100ml |
| Ports | 1/4" compression tube ports x 6 |
| Flange Type | DN80ISO-K |
| Working Temperature | RT - 600Ā°C Max |
| Working Pressure | Vacuum: 10e-3 Torr by mechanical pump, or 10e-5 torr by a turbopump Positive pressure: 3 bar |
| Net Weight | 3.5Kg |
| Application | Crucible for melting Li and other alloys Reactor of molten salt rechargeable battery |
Ā
Original: $1,798.00
-65%$1,798.00
$629.30More Images
SS316 Reaction Vessel (1100 ml) with 6 x 1/4" Feedthrough Ports for VBF-600S - RC-SS1100FT6
RCSS31676 is an SS316 stainless steel tube with a vacuum flange and six 1/4" dia. feedthroughs, designed for the reactor of a molten salt battery.
For the furnace used with VBF-600S vessel, please choose VBF1200S
| Structure | SS316 Stainless Steel |
| Dimension
|
Ā 76mm OD x 70mm ID x 300 mm height
|
| Volume | 1100ml |
| Ports | 1/4" compression tube ports x 6 |
| Flange Type | DN80ISO-K |
| Working Temperature | RT - 600Ā°C Max |
| Working Pressure | Vacuum: 10e-3 Torr by mechanical pump, or 10e-5 torr by a turbopump Positive pressure: 3 bar |
| Net Weight | 3.5Kg |
| Application | Crucible for melting Li and other alloys Reactor of molten salt rechargeable battery |
Ā
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
RCSS31676 is an SS316 stainless steel tube with a vacuum flange and six 1/4" dia. feedthroughs, designed for the reactor of a molten salt battery.
For the furnace used with VBF-600S vessel, please choose VBF1200S
| Structure | SS316 Stainless Steel |
| Dimension
|
Ā 76mm OD x 70mm ID x 300 mm height
|
| Volume | 1100ml |
| Ports | 1/4" compression tube ports x 6 |
| Flange Type | DN80ISO-K |
| Working Temperature | RT - 600Ā°C Max |
| Working Pressure | Vacuum: 10e-3 Torr by mechanical pump, or 10e-5 torr by a turbopump Positive pressure: 3 bar |
| Net Weight | 3.5Kg |
| Application | Crucible for melting Li and other alloys Reactor of molten salt rechargeable battery |
Ā
